Enable or Disable Wake on LAN in Windows 10 (WOL)

Find out how to enable or disable the Wake on LAN (WOL) feature in Windows 10.

Wake-on-LAN (WOL) is an interesting feature that allows you to wake up or shut down your computer via a local network or the Internet. It works like a remote on/off button. If your hardware supports WOL, you can turn on the computer remotely.

The Wake on LAN (WOL) feature wakes the computer from a low-power state when the network adapter detects a WOL event, for example. B. a magic package. In general, this event is a specially created Ethernet package. Once you enable the Wake on LAN feature, your device will be able to detect and activate these magic packets with its MAC address. This means that you can wake up your computer by sending it a magic packet from another device on the network.

Wake-up behaviour in LAN

The default behavior in response to WOL events has changed from Windows 7 to Windows 10.

In Windows 7, the system shuts down in the classic shutdown state (S5) by default. Only a few motherboards were able to supply enough power to the network adapters to take the device out of S5 mode.

In Windows 10, the system defaults to a hybrid shutdown state (also known as fast start) (S4). And all devices are connected to D3. In this case, WOL is not supported by S4 or S5. In these cases, it is clear that network adapters are not enabled for WOL because users do not expect power consumption and low battery consumption in off mode. The WOL is therefore disabled by default. You must configure your operating system for WOL to work.

See also  5 Most Advanced Smartwatches In the World in 2024

Enable Wake Up Local Area Network (WOL) in Windows 10

  1. Open a BIOS or UEFI shell. Depending on your hardware, you may need to press Esc, Del, F1 or F2, etc. to access the BIOS during boot.
  2. Enable or disable the Power On By PCI-E or WOL (Wake-on-LAN) option in the power management settings.

  1. Now start Windows 10.
  2. Open the Device Manager.
  3. Expand the Network Adapter item on the left, and double-click your network adapter.Network adapter in the Device Manager
  4. In the Properties window, click the Advanced tab and select Wake On Magic Package from the Properties pane on the left.

  1. Select Enabled from the Value drop-down list.

You have enabled the WOL feature in Windows 10. Learning how to use it is useful now. Follow this link:

Using the Wake on LAN feature in Windows 10

Similarly, you can disable the Wake-on-Lan option via the dialog box described above. Interestingly, you can open it from the Network Connections folder for a specific adapter.

Disable Wake on Local Area Network (WOL) in Windows 10

  1. Open the control panel.
  2. Go to Control Panel – Network and Internet – Network Center.
  3. Click the Change Adapter Settings link on the right side of the page.

  1. Right-click the network adapter for which you want to disable the WOL function and select Properties from the menu.Pop-up Adapter Properties Menu
  2. In the Properties dialog box, on the Network tab, click the Configure

  1. In the Properties window, click on the Advanced tab and in the Properties pane on the left, select Wake up to Magic Pack.
  2. Select Off from the Value drop-down list.
See also  ZTE Warp Elite Factory Reset – How to Hard Reset

It’s done!

You can also set the Power On By PCI-E/WOL (Wake-on-LAN) option in the BIOS or UEFI to disable hardware support for WOL.

Please support us.

Vinero is counting heavily on your support. You can help the site continue to provide you with interesting and useful content and software by using these options:

frequently asked questions

Why did you decide to disable the Wake on LAN feature?

Why is the Wake-on-LAN feature usually disabled on laptops? Because Wake-on-LAN drains the battery quickly. … The Wake-on-LAN feature is best used when you want to turn on the computer when the battery is low. It is normally disabled because it is not needed when the computer starts normally.

How to disable Wake-up on Windows 10 local network?

To turn it off, press Windows key + X, then Power Options. Tap Select what the power buttons do, and then tap Change settings that are not currently available. Scroll down to Shutdown settings, uncheck Enable quick start (recommended), and then click Save changes.

How do I enable Wake on LAN in Windows 10?

Open Windows Device Manager, find your network device in the list, right-click on it and select Properties. Go to the Advanced tab, find Wake up on the magic pack in the list and enable it. Message: The Wake on LAN feature may not work on some computers using the quick start mode in Windows 8 and 10.
